Product Description
ICT
● Test points: 384 (standard) configurable 1280 points
● Open and short circuit: 1024 points about 1sec
● Resistance: 50-100MΩ±1%～5%
● Capacitance: 1PF-60mF±1%～5%
● Inductance: 1uH-60H±2%～5%
● Diode: 0.1-6V±1%～3%
● Zener diode: 0.1-15V
● The three-terminal voltage of the transistor is Vce saturation voltage β
● Field effect three-terminal test Vds, Cds
● Optocoupler and relay four-terminal test of their conduction voltage or resistance (maximum current 2A, maximum voltage 60V)
● Electrolytic capacitor models use the spectrum characteristics of the shell and abdominal muscles for detection, with a measurable rate of 100%
● RLC series frequency test or phase separation method
● IC integrated block IC Clamping Diode and DR mode test empty soldering
FCT
● FCT electrical test function is customized according to customer needs. It is only introduced as an example of common functions and is not a hard rule
● Voltage detection: AC and DC 0~500V
● Current detection: AC and DC 0~10A
● Digital input test: 32-channel digital signal acquisition, channel support expansion
● Digital output test: 32-channel digital signal output, output voltage 0~32V adjustable, channel support expansion.
● Waveform test: 4 waveform test channels, support for extended analog output; 2 0~32V voltage output.
